COB LED STRIP / COB-019
24V 10 mm RGB COB LED Strip
576D RGB
24V rgb COB LED strip, 576D RGB, with a 10 mm PCB and 62.5 mm cutting interval. Stated RGB wavelengths: 620nm/520nm/460nm. Match the configuration to the installation, supply and controls.
At a glance576D
- Input voltage
- 24V
- PCB width
- 10 mm
- Cutting interval
- 62.5 mm
- Light configuration
- RGB
10 mm PCB
Check the installation space against the 10 mm PCB. 576D RGB.
62.5 mm cutting interval
Cut at this model's designated markings and match the connectors and controls to the selected configuration.
RGB
Stated RGB wavelengths: 620nm/520nm/460nm. Match the controls to the light-color configuration.
LIGHT & CONTROL
Choose your configuration
Select a configuration for your project. Different white temperatures are separate product versions.
Selected configuration24V · RGBYour selection identifies the enquiry configuration; the photograph is not recolored.
SIZE & CUTTING
10 mm PCB
62.5 mm cutting interval
This model uses 6.25 cm cutting sections. Follow the actual cutting marks and allow space for the PCB and connections.
Cutting relationship only · Not a scaled engineering drawing. Refer to the product for pads and wiring.
TECHNICAL SPECIFICATIONS
Model specifications
576D RGB
Power and chip count retain their stated values. Confirm their reference length before calculating supplies or comparing models.
| Internal reference | COB-019 |
|---|---|
| Product version | 576D RGB |
| Input voltage | 24V |
| Input supply type | AC/DC and the matching supply system to confirmConfirm before ordering |
| Light color / control type | RGB |
| PCB width | 10 mm |
| Cutting interval | 62.5 mm |
| Stated power (source value) | 12W · reference length to confirmConfirm before ordering |
| Chip count (source value) | 576PCS · reference length to confirmConfirm before ordering |
| RGB wavelengths | 620nm/520nm/460nm |
BEFORE YOU ORDER
Selection & ordering
- The stated 12W power and 576PCS chip count have no reference length. Confirm the basis before ordering; do not treat them as per-metre values.
- Voltage specification: 24V. Confirm AC/DC input, wiring and compatible supply and controls. Cut at this model's 62.5 mm marked interval.
- Confirm protection and any outdoor-use configuration. Confirm warranty and powered run length before ordering.
